End Gap Control System

MAINTAINS THE OPTIMUM GAP AT END DOWNSTACKERS THROUGH SMOOTH, RESPONSIVE LINE SPEED CONTROL

BENEFITS & FEATURES

Simple, Quick Installation

Initial adjustment is made simply by pressing two protected buttons. The integral microprocessor takes care of the rest. The instantaneous response maintains the correct gap and smooth flow of ends without interruptions. The result is optimum line control without the need for fine tuning.

Smooth, Modulated Control

End handling systems that use clutches to control product flow in response to stop-start signals from basic proximity sensors are jerky, inefficient and demand high maintenance. They can now be replaced by smooth, modulated, analog control. End lines run better, more reliably and with less need for maintenance.

Reduced Maintenance Costs

Adjustment is achieved by pressing just two protected push-buttons. The built-in microprocessor takes care of the rest. Instant response without overshoot will maintain the correct gap size and keep the ends moving without interruption. The result is perfect control with no complications, no fuss and no need for fine tuning.


Improved Line Performance

Consistent and stable end conveying helps lines to run at maximum efficiency. Interruptions due to clutch wear and breakdown are eliminated. Gap sizes can be kept small to prevent end inversion and the problems this creates, such splashing of water based compound or seamer wrecks on the customer’s filling line.

end_gap_diagram

End Gap Diagram

Linear analog output from a single wide faced sensor is used to smoothly adjust line speed and maintain an optimum end gap.
